How To Login To a Vmware Tanzu TKG/VKS Node

October 8, 2026 Victor DevOps, Containerization, Kubernetes 0

Last updated: October 2026

In this lesson, you will learn how to login to a Vmware Tanzu TKG/VKS Node

Understanding The Subject Matter

There are situations where you may need to log in directly to a VMware Tanzu Kubernetes Grid Service (Tanzu VKS) node for troubleshooting or investigation.

For example, you may need to investigate:

  • High CPU or memory utilization
  • Disk or filesystem issues
  • Container runtime problems
  • Kubernetes node-level issues
  • Network connectivity problems
  • Operating system-level issues

In this post, I will show you how to log in to a VKS or TKG node using the Supervisor Cluster.

Important: Direct SSH access to VKS nodes should normally be used for troubleshooting and investigation. Avoid making changes directly on a VKS node unless you understand the impact and the change is supported.

A VKS cluster consists of Kubernetes control-plane and worker nodes. These nodes are managed by VMware’s Kubernetes infrastructure.

When you have access to the Supervisor Cluster, you can use kubectl to retrieve information about the VKS cluster and its virtual machines.

The general process is:

  1. Connect to the Supervisor/ Supervisor Cluster.
  2. Identify the Supervisor namespace, and the VKS cluster (Note: VKS Supervisor namespace is different from VKS Kubernetes namespace)
  3. Identify the VM/node you want to access.
  4. Retrieve the SSH credentials associated with the VKS cluster.
  5. Decode the credential if necessary.
  6. Connect to the node using SSH.
  7. If password authentication fails, use the SSH private key.

Suggested Read: Kubernetes Pod Storage: How Pods Use Node Disk Space
Suggested Watch: How To Configure & Use Istio on Kubernetes Cluster – Canary Deployment – Istio Gateway

ACTION TIME

Step 1: Connect to the Supervisor Cluster

First, switch your kubectl context to the Supervisor Cluster.

[tekneed_Victor@vks01 ~]$ k config use-context reg1supv.tekneed.com

Switched to context "reg1supv.tekneed.com".

You can confirm that you are connected to the Supervisor Cluster by listing the namespaces (supervisor namespaces not VKS k8s namespaces):

[tekneed_Victor@vks01 ~]$ k get ns

NAME                                        STATUS   AGE
production-lag-01                           Active   92d
production-lag-02                           Active   94d
production-lag-03                           Active   92d
production-lag-04                           Active   92d
argocd                                      Active   109d
default                                     Active   117d
kube-node-lease                             Active   117d
kube-public                                 Active   117d
kube-system                                 Active   117d
production-lag-05                           Active   115d
svc-argocd-service-domain-xxxxxxx           Active   109d
svc-cci-ns-domain-xxxxxxx                   Active   116d
svc-contour-domain-xxxxxxxx                 Active   104d
svc-harbor-domain-xxxxxxx                   Active   99d
svc-tkg-domain-xxxxxxx                      Active   117d
svc-tmc-xxxxxxx                             Active   117d
svc-velero-domain-xxxxxxxx                  Active   117d
test                                        Active   91d
velero                                      Active   96d
vgcharborregistry                           Active   98d
production-lag-06                           Active   91d
vmware-system-ako                           Active   117d
vmware-system-appplatform-operator-system   Active   117d
vmware-system-cert-manager                  Active   117d
vmware-system-csi                           Active   117d
vmware-system-imageregistry                 Active   117d
vmware-system-kubeimage                     Active   117d
vmware-system-license-operator              Active   117d
vmware-system-logging                       Active   117d
vmware-system-monitoring                    Active   117d
vmware-system-netop                         Active   117d
vmware-system-nsop                          Active   117d
vmware-system-pinniped                      Active   117d
vmware-system-supervisor-services           Active   117d
vmware-system-vks-public                    Active   116d
vmware-system-vmop                          Active   117d
Login To a Vmware Tanzu TKG/VKS Node

Step 1B: Identify the VKS Node you want to log in to (optional step)

Once you know the namespace containing the Supervisor cluster, you can list the virtual machines in that namespace.

[tekneed_Victor@vks01 ~]$ k get vm -o wide -n production-lag-03

NAME                         POWER-STATE  CLASS      IMAGE             PRIMARY-IP4
production-lag-03-xxxx-xxxxx PoweredOn master-vm vmi-xxxxxxxxxxxxxxxx 10.10.10.86
production-lag-03-xxxx-xxxxx PoweredOn master-vm vmi-xxxxxxxxxxxxxxxx 10.10.10.199 production-lag-03-xxxx-xxxxx PoweredOn master-vm vmi-xxxxxxxxxxxxxxxx 10.10.10.92 production-lag-03-xxxx-xxxxx PoweredOn master-vm vmi-xxxxxxxxxxxxxxxx 10.10.10.231

Step 2: Retrieve the SSH Password

[tekneed_Victor@vks01 ~]$ k get secrets production-lag-03-ssh-password -o yaml -n production-lag-03

apiVersion: v1
data:
  ssh-passwordkey: gejwjwgeg3288wwbeddweqheggehskegs=
kind: Secret
metadata:
  annotations:
    kubernetes.vmware.com/password-update-last-timestamp: "2026-08-27T13:33:19Z"
  creationTimestamp: "2026-06-05T13:33:12Z"
  name: production-lag-03-ssh-password
  namespace: production-lag-03
  ownerReferences:
  - apiVersion: cluster.x-k8s.io/v1beta2
    kind: Cluster
    name: production-lag-03
    uid: hdhskks-dnenbsw-dnssmm-mnea-heh283
  resourceVersion: "122356262"
  uid: hdhskks-dnenbsw-dnssmm-mnea
type: Opaque

step 3: Decode the Base64 Password

Notice that the value of ssh-passwordkey is Base64 encoded.

You can decode it with:

echo "<BASE64_ENCODED_PASSWORD>" | base64 -d
[tekneed_Victor@vks01 ~]$ echo "gejwjwgeg3288wwbeddweqheggehskegs=" |base64 -d

tebaq7dwwkkwkewiehfqhlhqqhhqhw372a[tekneed_Victor@vks01 ~]$

Step 4: SSH Using the Password

[tekneed_Victor@vks01 ~]$ ssh vmware-system-user@10.10.10.231

vmware-system-user@10.10.10.231's password:
Permission denied, please try again.
vmware-system-user@10.10.10.231's password:
Permission denied, please try again.
vmware-system-user@10.10.10.231's password:
vmware-system-user@10.10.10.231: Permission denied (publickey,password).
[tekneed_Victor@vks01 ~]$

Depending on the state of the cluster and its SSH configuration, password authentication may not work, just as we have seen above.

For example:

Permission denied, please try again. Permission denied, please try again. Permission denied (publickey,password).

If this happens, you can use the SSH private key associated with the VKS cluster.

Using the SSH Private Key

Step 5: Retrieve the SSH Private Key

The VKS cluster also has an SSH secret containing the private key.

[tekneed_Victor@vks01 ~]$ k get secret production-lag-03-ssh -n production-lag-03 -o yaml

apiVersion: v1
data:
  ssh-privatekey: 22whwwejelweowjehdfh74203wjenw8034wjnwnsn0wn3nwnsnsnnsssjsjsjsbbsbssbsbsbbssmsdcffsjjedswsjsrjsjerwkrhshhhskrhrh740308e58305830853843hhhekdkhhdkshdhskshfskhfsskskskkshhrhrrhhhss84830848308583939838nbdgdhifsuehhdsiuhdisuheisigiiskhshhedhhw9e978s9s9sshhhdhs88337w937474747shsbgdhjsgdgsjsggdssjsejs88308384843030038484803030483hbbsss..................................
kind: Secret
metadata:
  creationTimestamp: "2026-06-05T13:33:12Z"
  name: production-lag-03-ssh
  namespace: production-lag-03
  ownerReferences:
  - apiVersion: cluster.x-k8s.io/v1beta2
    kind: Cluster
    name: production-lag-03
    uid: hdhskks-dnenbsw-dnssmm-mnea-heh283
  resourceVersion: "23626856"
  uid: hdhskks-dnenbsw-dnssmm-mnea-heh283
type: kubernetes.io/ssh-auth

Step 6: Decode the Private Key

You can decode the private key and save it to a file.

[tekneed_Victor@vks01 ~]$ echo 22whwwejelweowjehdfh74203wjenw8034wjnwnsn0wn3nwnsnsnnsssjsjsjsbbsbssbsbsbbssmsdcffsjjedswsjsrjsjerwkrhshhhskrhrh740308e58305830853843hhhekdkhhdkshdhskshfskhfsskskskkshhrhrrhhhss84830848308583939838nbdgdhifsuehhdsiuhdisuheisigiiskhshhedhhw9e978s9s9sshhhdhs88337w937474747shsbgdhjsgdgsjsggdssjsejs88308384843030038484803030483hbbsss |base64 -d > production-lag-03.keys

The private key is now stored in: production-lag-03.keys

Step 7: SSH Into the VKS Node Using the Private Key

[tekneed_Victor@vks01 ~]$ ssh -i production-lag-03.keys vmware-system-user@10.10.10.231

@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@
@         WARNING: UNPROTECTED PRIVATE KEY FILE!          @
@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@
Permissions 0664 for 'production-lag-03.keys' are too open.
It is required that your private key files are NOT accessible by others.
This private key will be ignored.
Load key "production-lag-03.keys": bad permissions
vmware-system-user@10.10.10.231's password:

If you try to use the private key without changing its permissions, SSH may reject it, WHICH IT DID in this case

This happens because SSH does not want a private key to be readable or writable by other users. Hence, you need to change the permission.

Step 8: Set the Correct Permissions

[tekneed_Victor@vks01 ~]$ chmod 400 production-lag-03.keys

You can verify the permissions with; ls -l production-lag-03.keys. The important part is that only the owner can read the file.

Step 8: SSH Into the VKS Node Using the Private Key

You can now use the private key to connect to the node

[tekneed_Victor@vks01 ~]$ ssh -i production-lag-03.keys vmware-system-user@10.10.10.231
Welcome to Ubuntu 24.04.3 LTS (GNU/Linux 6.8.0-90-generic x86_64)

 * Documentation:  https://help.ubuntu.com
 * Management:     https://landscape.canonical.com
 * Support:        https://ubuntu.com/pro

 System information as of Tue Sep  8 01:11:50 PM UTC 2026

  System load:  0.75               Processes:             204
  Usage of /:   49.1% of 19.02GB   Users logged in:       0
  Memory usage: 45%                IPv4 address for eth0: 10.10.10.231
  Swap usage:   0%

 * Canonical Workshop gives developers fast, composable, reproducible, and
   secure developer environments that are perfect for agentic workflows.

   https://ubuntu.com/workshop

Expanded Security Maintenance for Applications is not enabled.

0 updates can be applied immediately.

Enable ESM Apps to receive additional future security updates.
See https://ubuntu.com/esm or run: sudo pro status


The list of available updates is more than a week old.
To check for new updates run: sudo apt update

Last login: Thu Sep  3 12:42:30 2026 from 10.10.10.14
vmware-system-user@production-lag-03-XXXX-XXXX:~$

Conclusion

Logging directly into a VMware Tanzu TKGI/VKS node is useful when Kubernetes-level commands are not enough and you need to investigate what is happening at the operating-system or VM level.

The important thing to remember is that you can retrieve the VKS node’s SSH credentials from the Supervisor Cluster. If password-based authentication does not work, the SSH private key stored in the cluster’s SSH secret can be decoded and used for authentication.

Also, always protect the private key with appropriate file permissions before using it:

chmod 400 production-lag-03.keys

Once connected, commands such as free -h, df -h, top, ip addr, systemctl, and container-runtime commands can help you investigate issues directly from the node.
